3.0mm To 2.0mm 12F Core Mtp To LC Mpo Patch Cord

Ask Lasest Price
Brand Name :	Senko / US CONEC / Furukawa Connector
Model Number :	MPO UPC -LC UPC MM 12F
Certification :	ISO9001:2015
Price :
Payment Terms :	L/C, T/T, Western Union
Supply Ability :	50K
Delivery Time :	3-5 working days

Add to Cart

Product Details
Company Profile

3.0mm To 2.0mm 12F Core Mtp To LC Mpo Patch Cord

Beige mpo mtp to LC 12F cores fiber optic patch cord 3.0mm to 2.0mm

Product Description

MPO trunk multicore cable assemblies facilitate rapid deployment of high density backbone cabling in data centers and other high fiber environment, reducing network installation or reconfiguration time and cost, they are used to interconnect cassettes, plane or fan outs.
It offered in fiber types in standard 8, 12, 24 or 48 cores versions using a compact and rugged micro cables structure.

Advantages

Imported production and test equipments:EXFO IL&RL Tester/ Domaille Grinding Machine/ SENKO 3D Interferometer
Pretty high return loss:≥45dB
5-year Experience R&D Team
Customized Production and Service
40G/100G Data Center Solution

Application

1) Data communication network
2) Optical system access network
3) Storage area network fiber channel
4) High density architectures

Technical Parameter

Item	Technical Parameter
Connector	MPO (Female)	LC
Operation Temperature	-40°C ~ +80°C
Storage Temperature	-40°C ~ +85°C
Insertion Loss	SM: ≤ 0.75dB (standard value), ≤0.35dB (typical value); MM:≤ 0.50dB (standard value), ≤0.35dB (typical value);	SM:≤ 0.2dB; MM:≤ 0.2dB;
Return Loss	SM:≥60dB; MM:≥35dB;	SM:≥60dB; MM:≥35dB;
The MPO end type	Male: with guide pin; Female: without guide pin
Fiber count	8,12&24 MT fiber
The other end of the connector type	MPO-female , MPO-male , FC , SC , ST , MU , LC , E2000
Fiber mode	Single-mode(G652,G655,G657), multi-mode (50, 62.5, OM2, OM3, OM4)
Fiber cable type	250um ribbon fiber,ribbon cable,Bundle fiber optic cable

Polarity
