QSFP+ 40G LX4 transceiver module,4 CWDM lanes MUX/DEMUX design

Ask Lasest Price
Brand Name :	CY COM
Model Number :	QSFP+ 40G LX4
Certification :	ISO9001:2015, ISO14001:2015, ROSH
Payment Terms :	T/T, Western Union
Supply Ability :	50k/Month
Delivery Time :	5-8 days

Add to Cart

Product Details
Company Profile

QSFP+ 40G LX4 transceiver module,4 CWDM lanes MUX/DEMUX design

Description
OM3358SX100 is a QSFP+ transceiver module designed for 2 km SM Fiber or 150m OM3/OM4 MM fiber
optical communication applications. It is compliant with IEEE 802.3-2018 40GBASE-LR4 (partly
compliant), IEEE 802.3-2018 Annex 86A, QSFP+ MSA standards. Digital diagnostic management
interface (DDMI) is realized by I2C interface in compliance with SFF-8636. The module is RoHS 2
compliant.
This module can convert 4-channel 10 Gbps electrical data to 4-channel optical signals, and multiplex
them into a single channel for 40 Gbps optical transmission. Similarly, it optically de-multiplexes a 40
Gbps input into 4-channel signals, and converts them to 4-channel output electrical data on the receiver
side. It has been designed to meet the harshest external operating conditions including temperature,
humidity and EMI interference.
Figure 1-1 Transceiver block diagram

Pin Descriptions
Figure 2-1 MSA compliant connector

Mechanical Specifications
Figure 3-1 Mechanical dimensions

Product Features
● QSFP+ MSA compliant
● IEEE 802.3-2018 compliant
● 4 CWDM lanes MUX/DEMUX design
● 4x 10G electrical interface (XLPPI)
● Maximum power consumption 3.5 W
● LC duplex connector
● 41.25 Gbps aggregate bit rate
● Up to 150 m transmission on OM3/OM4 fiber
without FEC
● Up to 2 km transmission on single mode fiber
without FEC
● Operating case temperature: 0°C to 70°C
● Single 3.3 V power supply
● I2C digital management interface
● RoHS 2 compliant

Applications
● 40GE Ethernet
● Data Center Interconnect
● Enterprise networking
